Technical Data
3A0420H 53
Technical Data
Volume
Mix Ratio
Pressure
Ratio
“A” Side
Pump
“B” Side
Pump
Combined
Fluid Output
cc/cycle
Maximum Air
Working Pressure
psi (MPa, bar)
Maximum Fluid
Working Pressure
psi (MPa, psi)
Flow Rate at
40 cycles/min
gpm (ltr/min)
1:1 76:1 Xtreme 85 Xtreme 85 173 95 (0.6, 6.5) 7250 (50, 500) 1.8 (6.9)
1.5:1 91:1 Xtreme 85 Xtreme 58 144 80 (0.5, 5.5) 7250 (50, 500) 1.5 (5.7)
2:1 76:1 Xtreme 115 Xtreme 58 174 95 (0.6, 6.5) 7250 (50, 500) 1.8 (6.9)
2.5:1 65:1 Xtreme 145 Xtreme 58 203 100 (0.7, 7) 6500, 45, 448) 2.1 (8.1)
3:1 68:1 Xtreme 145 Xtreme 48 193 100 (0.7, 7) 6800, 47, 469) 2.0 (7.7)
4:1 73:1 Xtreme 145 Xtreme 36 181 100 (0.7, 7) 7250 (50, 500) 1.9 (7.2)
Air inlet size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4 npsm(f)
Air consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 cfm at 100 psi inlet/gpm
0.56 cu meter/min at 7 bar/liter/min
Maximum air pressure supply to the sprayer . . . . . . . . . . . . . 175 psi (1 MPa, 12 bar)
Filtration:
Air inlet filtration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40-micron filter/separator included
XP70 pump outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 mesh
XTR7 Spray Gun. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 mesh
Fluid pump inlets without hoppers. . . . . . . . . . . . . . . . . . . . . . 1-1/4 in. npsm(m)
Fluid gauge manifold outlets . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2 in. npt(f)
Fluid mix manifold inlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8 in. npt(m) ball valves
Mix manifold material outlet . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2 in. npt(f)
Maximum feed pressure from remote source . . . . . . . . . . . . . 250 psi (1.7 MPa, 17 bar)
Fluid Viscosity Range:
Gravity feed with 7 gallon (26 liter) hoppers . . . . . . . . . . . . 200 to 20,000 cps (pourable)
Pressure feed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Any viscosity that will not require feed pressure more than 15%
of outlet pressure
Environmental Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Indoor/outdoor
Hazardous Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EX II 2 G c IIA T2
Ambient Temperature Range:
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40-130°F (4-54°C)
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-160°F (-1-71°C)
Maximum Fluid Temperature . . . . . . . . . . . . . . . . . . . . . . . 160°F (71°C)
Sound pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 dBA at 100 psi (0.7 MPa, 7 bar)
Sound power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98 dBA at 100 psi (0.7 MPa, 7 bar)
Wetted materials:
Housings and manifolds . . . . . . . . . . . . . . . . . . . . . . . . . . . Carbon steel with electroless nickel plating
Miscellaneous parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Plated carbon steel, stainless steels, carbide, acetal, UHM-
WPE, nylon, PTFE solvent resistant plastics
Pump packings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Carbon filled PTFE
Flush pump suction tube. . . . . . . . . . . . . . . . . . . . . . . . . . . Aluminum
Hoses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nylon core
Weight:
Full System with heaters, solvent flush pump, and hoppers 575 lbs (260 kg)
Bare system with no heaters, solvent flush pump, or hoppers 425 lbs (192 kg)
Maximum Storage Time: 5 years (To maintain original performance, replace soft seals
after 5 years of inactivity.)
Maximum Lifetime: Indefinite with recommended maintenance and periodic
rebuilds for critical parts.
Power Efficiency Factor: 75 cu. ft compressed air/1 gallon sprayed material at 100 psi
0.56 m
3
compressed air /1 liter sprayed material at 0.7 MPa
(7 bar)
