Dimensions
54 3A0420H
Dimensions
6.75 in.
(171.45 mm)
16.90 in.
(429.26 mm)
40 in.
(1016 mm)
15.25 in.
(387.35 mm)
22 in.
(558.8 mm)
32 in.
(812.8 mm)
32 in.
(812.8 mm)
52 in.
(1320.8 mm)
60 in.
(1524 mm)
r_571100_3a0420_101a
r_571100_3a0420_100a
35 in.
(889 mm)
Full SystemBare System
Top VIew
Side VIew
Floor Mounting Dimensions
Top VIew
