Graco XP70 Instruction & Parts Manual

Related Manuals
3A0420H 3
Related Manuals
Manuals are available at www.graco.com
Component Manuals in English:
Manual Description
311762
Xtreme
®
Displacement Pumps
Instructions-Parts
311238
NXT
®
Air Motor Instructions-Parts
3A0590
Mix Manifold
Instructions-Parts
312747
20 Gallon Double Wall Hopper Kit
Instructions-Parts
309524
Viscon
®
HP Heater Instructions-Parts
312145
XTR
™
5 and XTR
™
7 Spray Guns
Instructions-Parts
312769
Feed Pump and Agitator Kits
Instructions-Parts
312794
Merkur
®
Pump Assembly
Instructions-Parts
310863 Feed and Solvent Flush Kits
406860
7-Gallon Hopper Installation Kit
Instructions-Parts
406739 Desiccant Kit Instructions-Parts
309852
Polyurethane Circulation and Return
Tube Kits, Instructions-Parts
406861
Viscon HP Heater Adapter Kit, Instruc-
tions-Parts
3A0421 Ratio Check Kit, Instructions-Parts
309525 Heated Hose Kit, Instructions-Parts
309964
Gun Splitter Valve with Independent
Flush, Instructions-Parts
339361
High Pressure Hose and Accessories
Brochure
311486
DataTrak
™
Conversion Kit, Instruc-
tions-Parts

Graco XP70 Specifications

General

Fluid Output	2.0 gpm (7.6 lpm)
Fluid Delivery	2.0 gpm (7.6 lpm)
Maximum Fluid Working Pressure	7250 psi (500 bar)
Maximum Air Input Pressure	100 psi (7 bar)
Fluid Outlet Size	3/8 in npsm(m)
Wetted Parts	Stainless Steel, PTFE, UHMWPE
Maximum Pressure	7250 psi (500 bar, 50 MPa)
Hose Length	50 ft
