Parts
3A0420H 43
Parts Varying by Model with Hoppers
Parts Varying by Model with No Hoppers
Ref. Part Description
XP70 Plural-Component Sprayer Models
571102 571152 571202 571252 571302 571402
4 571100 PUMP, fixed ratio, 1:1
1
571150 PUMP, fixed ratio, 1.5:1
1
571200 PUMP, fixed ratio, 2:1
1
571250 PUMP, fixed ratio, 2.5:1
1
571300 PUMP, fixed ratio, 3:1
1
571400 PUMP, fixed ratio, 4:1
1
18 100131 NUT, full hex; 3/8-16 7 7 7 7 7 7
55 24E872 BRACKET, hopper,
painted
2 2 2 2 2 2
56 262479 HOPPER, blue
1 1 1 1 1 1
57 262480 HOPPER, green
1 1 1 1 1 1
60 H52506 HOSE, coupled, 5600 psi,
1.4 ID, 6 ft
2 2 2 2 2 2
61 16D376 FITTING, swivel, 1-1/4,
mod, w/plug
2 2 2 2 2 2
62 111192 BOLT, flange hd; 3/8-16 4 4 4 4 4 4
64 113498 VALVE, relief, air, 110 psi
1 1 1 1 1
116643 VALVE, relief, air, 90 psi
1
65 262482 STRAINER, hopper, 7 gal-
lon; 0.203 in. openings
2 2 2 2 2 2
66 124450 CLAMP, spring, con-
stant-tension
1 1 1 1 1 1
67▲ 15T468 LABEL, warning
2 2 2 2 2 2
Ref. Part Description
XP70 Plural-Component Sprayer Models
571101 571151 571201 571251 571301 571401
4 571100 PUMP, fixed ratio, 1:1
1
571150 PUMP, fixed ratio, 1.5:1
1
571200 PUMP, fixed ratio, 2:1
1
571250 PUMP, fixed ratio, 2.5:1
1
571300 PUMP, fixed ratio, 3:1
1
571400 PUMP, fixed ratio, 4:1
1
18 100131 NUT, full hex
3 3 3 3 3 3
60 H52510 HOSE; 1/4 x 10 ft
222222
64 113498 VALVE, relief, air, 110 psi
1 1 1 1 1
116643 VALVE, relief, air, 90 psi
1
