Parts
3A0420H 45
Common Parts
▲ Replacement Danger and Warning labels, tags, and
cards are available at no cost.
Varying Parts
❖ Included with B-Side pump assembly.
† Included with new pump assemblies (117, 118).
Ref. Part Description Qty.
101 262465 PLATE, motor 1
102 262466 ROD, tie, 4.00 long,1.00 dia 3
103 N65DN0 MOTOR, 6500, de-icing, standard 1
104 262467 ROD, adapter 1
105 262468 ROD, tie, 14.25 long, w/shoulder 4
106 262469 ROD, tie, 14.25 long, 1.25 dia 2
107 154636 WASHER, flat; 5/8 3
108 101712 NUT, lock; 5/8-11 9
109 16D451 NUT, yoke 1
110 262470 BRACKET, ratio indicator 1
111 262471 YOKE, pump assembly 1
112 15H392 ROD, adapter xtreme 2
113 262472 SLEEVE, bearing 2
114 15C244 BEARING, sleeve 4
116 123976 RING, snap, external 2
121 262473 COVER, motor rod 1
122 262474 COVER, pump 2
123 LABEL, identification 1
128 NXT102 KNOB, de-ice, 5 pack 1
129 16D029 LABEL, XP70 1
130 124078 CLAMP, spring, constant-tension 2
131▲ 15H108 LABEL, pinch point 1
133 114225 TRIM, edge protection 2
134 262475 BRACKET, ratio indicator 1
135 16E882 STRAP, lowers 2
136 SCREW, cap, button hd; 10-32 8
137 WASHER, retaining, nylon 8
138 124665 NUT, captive; 10-32 4
139▲ 15T468 LABEL, warning 2
141 206995 FLUID, tsl, 1 qt. 1
142 244524 WIRE, ground assembly with
clamp
1
Ref. Part Description Qty.
Ref. Description
Ratio 1:1 1.5:1 2:1 2.5:1 3:1 4:1
Qty.Part 571100 571150 571200 571250 571300 571400
117 A-Side pump
(see manual 311762)
L085C0 L085C0 L115C0 L14AC0 L14AC0 L14AC0 1
118 B-Side pump
(see manual 311762)
L085C0 L058C0 L058C0 L058C0 L048C0 L036C0 1
119† A-Side coupler
247167 247167 247167 244819 244819 244819 1
120† B-Side coupler
247167 247167 247167 247167 247167 247167 1
140❖ B-Side rupture disc
258962 258962 258962 258962 258962 1
