M AINTENANCE AND SERVICE
6–10
ACCESSORY WIRING COLOR – FUSE/BREAKER SIZES
290, 300, 305, 330, & 336 DC Wiring Char
t
Together Delivering the Ultimate Boating Experience!
Accessor
y
Wire Size & Colo
r
A
mperag
e
Fuse/Breaker Location
Lights
Bow Lights 14 ga. Gray 10.0 Accessory Panel
Cabin Lights 16 ga. Blue/Green (14 ga. 330) 10.0 (330 / 20) AC/DC Panel
Cockpit Lights 14 ga. Blue/Yellow 10.0 Accessory Panel
Livewell Light 16 ga. Blue/Red w/ Livewell Pump Accessory Panel
Mast Light 14 ga. Gray/Red w/ Bow Light Accessory Panel
Panel Lights 16 ga Dark Blue w/ Nav Lights Accessory Panel
Spreader Lights 14 ga Dark Blue/White 10.0
300 & 336 Fwd light HT Fuse Block / 305, 330 & 336
accessory switch panel
Pumps
Aft Bilge Pump (330 / 336 Fwd): -- -- --
Rule 1500 16 ga. Brown 8.0 Accessory Panel
Auto Float Switch (Aft) 16 ga. Brown/White 8.0 Battery Select Box
Fwd Bilge Pump: -- -- --
Rule 1100 16 ga. Brown/Black 6.0 Accessory Panel
Auto Float Switch (Forward) 16 ga. Brown/Red 6.0 Battery Select Box
Head Pump (Discharge) 14 ga. Orange/Gray 10.0 AC/DC Panel
Head Pump (Vaccum) 14 ga. Orange/Red 10.0 AC/DC Panel
Livewell Pump: Sentry 1100 GPH 16 ga. Orange/Brown 6.0 Accessory Panel
Power Assist Pump (main) 8 ga. Red 40.0 Battery Compartment
Power Assist Pump (ignition) 16 ga. Purple 5.0 Yamaha ignition panel (in line)
Shower Sump Pump (Float Switch) 16 ga. Brown/Orange 2.5 AC/DC Panel
Washdown Pump 12 ga. Orange/Brown 15.0 Accessory Panel
Water Pressure Pump 12 ga. Orange/Blue 15.0 AC/DC Panel
Anchor Windlas
s
Main Positive 6 ga. Red (300 & 305); 2 ga. Red (330 & 336) 35.0 (300 & 305); 90 (330 & 336) Battery Select Box
Positive to Switches 14 ga. Red 5.0 Accessory Panel
Down 14 ga. Green/Orange N/A N/A
Up 14 ga. Blue/Orange N/A N/A
Miscellaneou
s
12 Volt Accessory Outlets 10 ga. Red/Orange 15.0 Fuse Block
Accessory Negatives (Branch) (Note 1) Black N/A N/A
Accessory Negatives (Mains) 2, 6, or 10 ga. Black N/A N/A
Accessory Power Lead 2, 6, 10 ga. or 2/0 Red 50.0 Battery Select Box
Blower (330 Head Only) 16 ga. Brown/Green 4.0 Fuse Block
Blower (Bilge) 10 ga. Brown/Yellow 4.0 Generator Panel
CO Detector 16 ga. Red/Black 1.0 Positive bus (in line) / 336 console fuse block
Constant 12V (Memory) 16 ga. Red/Pink 10.0 Battery Select Box
Electronics Box Ram
(
305, 330 & 336
)
16 ga. White 5.0 Accessory Panel
Fuel Grounds 16 ga. Green N/A N/A
Fuel Tank Sender (Auxiliary) 16 ga. Pink/White N/A N/A
Fuel Tank Sender (Main) 16 ga. Pink N/A N/A
Hard Top Negative (Main) 10 ga. Black/Blue N/A Negative Bus
Hard Top Power Lead (Main) 10 ga. Red/Blue 40.0 Console fuse panel 305 only
Horn 12 ga. Orange/White 10.0 Accessory Panel
Hydraulic Trim Tabs 14 ga. Orange 20.0 Fuse Block
Refrigerator 10 ga. Orange/Yellow 15.0 AC/DC Panel
Seakey Float (300 only) 16 ga. White/Red N/A N/A
Stereo 16 ga. Red 10.0 AC/DC Panel
TV/DVD 10 ga. Red/Green 10.0 AC/DC Panel
Windshield Wiper (Actuator) -- -- --
300 Port / 300 Stbd 16 ga. Orange/Green / 16 ga. Orange/Black 10.0 Accessory Panel
305, 330, 336 16 ga. Orange/Black 5.0 Accessory Panel
Windshield Wiper (Park) 16 ga. Orange w/ power to switch Accessory Panel
(
Note 1
)
Wire
g
au
g
e is the same as the
g
au
g
e of the power wire to the correspondin
g
component.
