Grady-White 330 Express - Access Plate and Rigging Tube Locations

330 EXPRESS
8–23
Access Plate And Rigging Tube Locations
6" 6"6" 6"
6"
6"
6"
6" Access Plate
Bow Thruster Access
6" Access Plates
Description
3" X 32"
1 1/4" X 132"
3" X 80"
3" X 78"
3" x 120"
#
D
F
C
B
A
A
B
C
F
D
H
G 1 1/4" x 27"
1 1/4" x 25
G & H
E
E2" x 87"
