Grady-White 330 Express - Volt AC Wiring One Line Diagram

330 EXPRESS
8–41
120 Volt AC Wiring One Line Diagram
SHORE # 1
30A 30A
X
30A
MECHANICAL
INTERLOCK TO
PREVENT
SIMULTANEOUS
CLOSURE
BATTERY CHARGER
STOVE
WATER HEATER
MICROWAVE
HEAD OUTLET
CABIN OUTLETS
COCKPIT OUTLET
10A
25A
15A
15A
15A
15A
15A
GENERATOR
(SELF LIMITING)
5A
AIR COND
20A
REFRIGERATOR
5A
AIR/COOLER PUMP (OPTIONAL)
COCKPIT COOLERS (OPTIONAL)
15A
HELM AIR COND (OPTIONAL)
25A
AC MULTIMETER
A
AC AMPS
AC VOLTS
V
CURRENT TRANSFORMER
ACCY
10A
ACCY
10A
