Grady-White 330 Express - Liner Rigging Tubes

330 EXPRESS
8–22
Informational Drawings Liner Rigging Tubes
A
* the 2" pvc tube labeled "N" should be
centered on the liner's centerline
C
F
B
center line
of liner
E
D
N*
J
H
I
G
K
M
H
B
LengthPiece(s)
A, C, D, E, G, I
F, J
N
K, L, M
3" x 21"
2" x 18"
2" x 36"
3" x 33"
3" x 16"
3" x 42"
Reference Point
L
