Grady-White 330 Express - Diesel Generator Layout

330 EXPRESS
8–34
Diesel Generator Layout
OUT
IN
Battery Select Box
Coolant Resevoir
Muffler
Fischer Panda 4200
Diesel Generator
Sea Water Intake
Sea Water Strainer
Fuel Filter and Pump
in-line on stringer
13 Gallon Diesel
Fuel Tank
Vented Loop
Generator Control Panel
& Fuel Level Gauge
at AC/DC Panel
CO Monitor
