Grady-White 330 Express - Volt DC Anchor Windlass Diagram

330 EXPRESS
8–48
12 Volt DC Anchor Windlass Diagram
LINE
NO.
2 GA BLK
FROM DWG
330-DC-1-2
LINE 19
1. 2. 3. 4.
2 GA R
D1
A2
WINDLASS
SOLENOID
D2
2 GA R
2 GA R
18 GA BRN
UP
14 GA BLU/ORG 18 GA R
18 GA R
14 GA GRN/ORG
DOWN
18 GA BLU
14 GA R
UP DOWN
14 GA BLK
18 GA BLU/ORG 18 GA GRN/ORG
14 GA R 14 GA R
14 GA R
5.
WINDLASS
HELM
SWITCH
FROM DWG
330-DC-1-2
LINE 15
P8
P8 P8
WINDLASS
MOTOR
WINDLASS
FOOT
CONTROLS
5A (CB)
330-DC-7
