Grady-White 330 Express - Volt DC Lighting Diagram

330 EXPRESS
8–45
12 Volt DC Lighting Diagram
LINE
NO.
1.
FROM DWG
330-DC-2
LINE 6
MAIN ACC. DC NEG. BUS
LIGHTS TB
14 GA BLU/GN
16 GA BLK
14 GA BLU/GN
16 GA BLU/GN
14 GA BLU/GN
14 GA BLK
2.
3.
4.
6.
7.
5.
WW
WW
(BEHIND AC/DC PANEL)
FROM DWG
330-DC-1-1
LINE 2
(BEHIND AC/DC PANEL)
MAIN CABIN
DOME LTS
SWITCH
16 GA BLK
GALLEY &
DINETTE DOME
LTS W/ SW
P9
RECESS LTS
SWITCH
ROPE LTS
14 GA BLK
ROPE LTS
SWITCH
WW
14 GA BLK
14 GA BLU/GN
14 GA BLU/GN
16 GA BLU/GN
16 GA BLU/GN
WW
16 GA BLK
16 GA BLU/GN 16 GA BLU/GN
16 GA BLU/GN
AFT BERTH DOME
& READING LTS
W/ SW
16 GA BLK
12 GA BLU/GN
P9
14 GA BLU/GN
14 GA BLK
RECESS LTS
14 GA BLU/GN
W
14 GA BLK
GALLEY RAIL LT
W/ SW
HEAD RAIL LT
W/ SW
16 GA BLU/GN
16 GA BLK
W
W
16 GA BLU/GN
8.
HEAD DOME
LT W/ SW
16 GA BLK
16 GA BLK
DINETTE
READING LTS
W/ SW
9.
16 GA BLU/GN
W
16 GA BLU/GN
W
16 GA BLK
12 GA BLU/GN
NOTES:
1) SEE LAYOUT DRAWINGS FOR COMPONENT LOCATIONS
330-DC-4
