Grandstream Networks GXW-4024 User Manual

Grandstream Networks, Inc. GXW4024 User Manual Page 20 of 35
Firmware 1.0.1.8 Last Updated: 5/2008
DEFINITIONS
This section will describe the options in the Web configuration user interface. As mentioned, a user can
log in as an administrator or end-user.
Functions available for the end-user are:
• STATUS: Displays the network status, account status, software version and MAC-address of the
phone
• BASIC SETTINGS: Basic preferences such as date and time settings, multi-purpose keys and
LCD settings can be set here.
Additional functions available to administrators are:
• ADVANCED SETTINGS: To set advanced network settings, codec settings and XML
configuration settings.
• PROFILE X: To configure each of the SIP accounts.
• FXS PORTS: To configure each of the FXS ports and Hunting Groups etc.
T
ABLE 7: BASIC SETTINGS
End User Password
Password to access the Web Configuration Menu.
This field is case sensitive with a maximum length of 25 characters.
Web Port
By default, HTTP uses port 80. This field is for customizable web port.
Telnet Server
Default is Yes.
IP Address
There are two modes to operate the GXW4024 :
DHCP mode: all the field values for the Static IP mode are not used (even though they
are still saved in the Flash memory.) The GXW4024 acquires its IP address from the first
DHCP server it discovers from the LAN it is connected.
Using the PPPoE feature: set the PPPoE account settings. The GXW4024 will establish
a PPPoE session if any of the PPPoE fields is set.
Static IP mode: configure the IP address, Subnet Mask, Default Router IP address,
DNS Server 1 (primary), DNS Server 2 (secondary) fields. These fields are set to zero by
default.
DHCP hostname
This option specifies the name of the client. This field is optional but may be required by
some Internet Service Providers. Default is blank.
DHCP domain
This option specifies the domain name that client should use when resolving hostnames
via the Domain Name System. Default is blank.
DHCP vendor class ID
Used by clients and servers to exchange vendor-specific information. Default is HT500.
PPPoE account ID
PPPoE username. Necessary if ISP requires you to use a PPPoE (Point to Point
Protocol over Ethernet) connection.
PPPoE password
PPPoE account password.
PPPoE Service Name
This field is optional. If your ISP uses a service name for the PPPoE connection, enter
the service name here. Default is blank.
Time Zone
Controls how the date/time is displayed according to the specified time zone.
