TABLE 10: FXS PORTS SETTINGS
FXS Port
FXS Port Number
SIP User ID User account information, provided by VoIP service provider (ITSP). Usually in the form
of digit similar to phone number or actually a phone number.
Authenticate ID
SIP service subscriber’s Authenticate ID used for authentication. Can be
identical to or different from SIP User ID.
Password
SIP service subscriber’s account password for GXW4024 to register to (SIP) servers of
ITSP.
Name
Any Name to identify this specific user.
Profile ID
Select the corresponding Profile ID (1 or 2)
Hunting Group
This feature enables the gateway to register all existing FXS ports with the same phone
number. Each incoming call will be routed to first available port in round robin mode.
User may configure all ports as members of the same Hunt Group or it may configure
different port combinations for more than one Hunt Group.
For example: Ports 1, 3 and 5 may be members of the same hunt group, the rest of the
ports may have separate numbers and may be reached independently.
Select appropriate value for Hunting Group feature. The original SIP account should be
set to Active while the group members should be set to the port number of the Active
Port.
Example configuration of a multiple hunt group:
FXS Port #1: SIP UserID and Authenticate ID entered, Hunting group set to "Active"
FXS Port #2: SIP UserID and Authenticate ID left blank, Hunting Group set to "1"
FXS Port #3: SIP UserID and Authenticate ID left blank, Hunting Group set to "1"
FXS Port #4: SIP UserID and Authenticate ID entered, Hunting group set to "Active"
FXS Port #5: SIP UserID and Authenticate ID left blank, Hunting Group set to "4"
FXS Port #6: SIP UserID and Authenticate ID left blank, Hunting Group set to "4"
FXS Port #7: SIP UserID and Authenticate ID entered, Hunting group set to "Active"
FXS Port #8: SIP UserID and Authenticate ID left blank, Hunting Group set to "7"
Hunt Group 1 contains ports 1, 2, 3. Hunt Group 4 contains ports 4, 5, 6. Hunt Group 7
contains ports 7, 8.
