Grandstream Networks, Inc. GXW4024 User Manual Page 9 of 35
Firmware 1.0.1.8 Last Updated: 5/2008
DTMF Method
flexible DTMF transmission method; User choice of In-Audio, RFC2833,
and/or SIP Info
IP Signaling
SIP (RFC 3261)
Provisioning
TFTP, HTTP and HTTPS
Control
TLS/SIPS
Management
Syslog, remote management using Web browser and telnet
Dial Plan
Yes
Power
Input: 100–240 VAC/50-60 Hz
Output: 12VDC, 3.0A
Mounting
Rack or Wall
Short and long haul
REN2: Up to150 ft on 24 AWG line
Caller ID
Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID
Polarity Reversal /
Wink
Yes
EMC
EN55022/EN55024 and FCC part15 Class B
Safety
UL
H
ARDWARE SPECIFICATION
The hardware specifications of the GXW4024 are detailed in Table 4.
T
ABLE 4: HARDWARE SPECIFICATION OF GXW4024
Ports
24 FXS Ports
LAN interface
1 x RJ45 10/100Mbps
LED
24 LEDs for FXS port status (GREEN)
Other LEDs for operation status
Universal Switched
Power Adaptor
Input: 100-240V AC, 50/60Hz
Output: 12V DC, 3.0A, UL certified
Dimension
445mm (L) x 269mm (W) x 44.5mm (H), or 1U
Weight
6.3 lbs (2.8 kg)
Temperature
32~104°F / 0~40°C
Humidity
10% - 90% (non-condensing)
Compliance
FCC, CE, C-Tick
