Grandstream Networks, Inc. GXW4024 User Manual Page 22 of 35
Firmware 1.0.1.8 Last Updated: 5/2008
Table 9: ADVANCED SETTINGS
Admin Password
Administrator password. Only the administrator can configure the “Advanced Settings” page.
Password field is purposely left blank for security reasons after clicking update and saved. The
maximum password length is 25 characters.
Layer 3 QoS
This field defines the layer 3 QoS parameter which can be the value used for IP Precedence or
Diff-Serv or MPLS. Default value is 0.
Layer 2 QoS Value used for layer 2 VLAN tag. Default setting is blank.
STUN Server
IP address or Domain name of the STUN server.
Keep-alive
interval
This parameter specifies how often the GXW4024 sends a blank UDP packet to the SIP server to
keep the “hole” on the NAT open. Default is 20 seconds.
Firmware Upgrade
& Provisioning
Enables GXW4024 to download firmware or configuration file through TFTP, HTTP or HTTPS
server.
Via TFTP Server
This is the IP address of the configured TFTP server. If selected and it is non-zero or not blank,
the GXW4024 retrieves the new configuration file or new code image from the specified TFTP
server at boot time. After 5 attempts, the system will timeout and then it will start the boot
process using the existing code image in the Flash memory. If a TFTP server is configured and a
new code image is retrieved, the new downloaded image is saved into the Flash memory.
Note: Please do NOT interrupt the TFTP upgrade process (especially the power supply) as this
will damage the device. Depending on the network environment this process can take up to 15
or 20 minutes.
Via HTTP or
HTTPS Server
The URL for the HTTP/HTTPS server used for firmware upgrade and configuration via HTTP.
For example, ttp://provisioning.mycompany.com:6688/Grandstream/1.0.1.8
“:6688” is the specific TCP port where the HTTP server is listening; it can be omitted if using
default port 80.
Note: If Auto Upgrade is set to No, GXW4024 will only do HTTP download once at boot up.
Firmware Server
Path
IP address or domain name of firmware server.
Config Server
Path
IP address or domain name of configuration server.
Firmware File
Prefix
Default is blank. If configured, GXW4024 will request firmware file with the prefix. This setting is
useful for ITSPs. End user should keep it blank.
Firmware File
Postfix
Default is blank. End user should keep it blank.
Config File Prefix
Default is blank. End user should keep it blank.
Config File Postfix
Default is blank. End user should keep it blank.
Allow DHCP
Option 66 to
override server
If set to “Yes”, configuration and upgrade server’s information can be obtained using DHCP
option 66 from DHCP server located in customer’s environment.
Automatic
Upgrade
Choose “Yes” to enable automatic upgrade and provisioning. When set to “No”, GXW4024 will
only do upgrade once at boot up.
When “Check every day” or “Check every week” is checked, user can specify “Hour of the day(0-
23)” or “Day of the week(0-6)”. Default time is Monday 1AM.
There are three options to choose from: “Always check for New Firmware at Boot up”, “Check
New Firmware only when F/W pre/suffix changes”, and “Always Skip the Firmware Check”.
