CONNECT YOUR GXW400X GATEWAY
Connecting the GXW400X gateway is easy. Before you begin, please verify the contents of the GXW400X
package.
Equipment Packaging
Unpack and check all accessories. Equipment includes:
one device unit
one RJ45 Ethernet cable
one 12V universal power adapter
Connect the GXW400X
Follow these four (4) steps to connect your GXW400X gateway to the Internet and access the unit’s
configuration pages.
1. Connect standard touch-tone analog phones to the FXS ports.
2. Insert an RJ45 Ethernet cable into the WAN port of GXW400X and connect the other end to an
uplink port (a router or a modem, etc.) Note: If the gateway is used in router mode, connect a PC
to the LAN port of GXW400X for initial configuration.
3. Plug the power adapter into the GXW400X gateway into a power outlet.
Follow the instructions from the topic “Configuring GXW 400X with Web Browser” for initial configuration.
The GUI pages will guide you through the remaining steps to set-up your gateway. Examples of the GUI
Interfaces can be downloaded from:
http://www.grandstream.com/sites/default/files/Resources/gxw400x_gui.zip.
Figure 1: Diagram of GXW4004-8 back panel
