GXW400X User Manual
Play busy/reorder
tone before Loop
Current Disconnect
Default is No. If set to Yes, it will play busy/reorder tone before loop current
disconnect upon call fail.
Loop Current
Disconnect duration
Default is 200. In 100 - 1 0000 milliseconds range.
Proxy-Require
SIP Extension to notify SIP server that the unit is behind the NAT/Firewall.
Enable Hook Flash
Default is Yes. If set to “No”, FLASH button could only be used for terminating
calls.
Hook Flash timing
Time period when the cradle is pressed (Hook Flash) to simulate FLASH. To
prevent unwanted activation of the Flash/Hold and automatic phone ring-back,
adjust this time value.
On Hook Timing
On-hook timing is the minimum time for an on-hook event to be validated.
Gain
Handset volume adjustment. RX is for receiving volume (direction FXSto
analog phone), TX is for transmission volume (Analog phone to FXS). Default
values are 0dB for both parameters. Loudest volume: +6dB Lowest volume:
-6dB.
Ring Tones
Configure ring cadences according to preference.
Saving the Configuration Changes
After user makes a change to the configuration, press the “Update” button in the Configuration Menu. The
web browser will then display a message window to confirm saved changes.
Grandstream recommends reboot or power cycle the IP phone after saving changes.
