Sets the LAN subnet mask. Default value is 255.255.255.0
Base IP for the LAN port which functions as a Gateway for the subnet.
Default value is 192.168.2.1.
When the device detects WAN IP is conflicting with LAN IP, the LAN base IP
address will be changed based on the network mask -- the effective subnet
will be increased by 1. For example; 192.168.2.1 will be changed to
192.168.3.1 if net mask is 255.255.255.0. Then the device will reboot
Value is set in units of hours. Default value is 120 hrs (5 Days.) The time
IP address is assigned to the LAN clients.
Forward all WAN IP traffic to a specific IP address if no matching port is used
by GXW400X or defined in port forwarding.
Forwards a matching (TCP/UDP) port to a specific LAN IP address with a
specific (TCP/UDP) port.
In addition to the Basic Settings configuration page, end users also have access to the Device Status page.
Table 9: Status page
The device ID in hexadecimal format. This is needed for Internet Service
Provider troubleshooting. Note: there are separate MAC addresses for the
WAN side and the LAN side. The LAN MAC address will be used for
provisioning and can be found on the label on original box and on the label
located on the bottom panel of the device.
