CE5000-UM-251-9370 6-16
6 DISASSEMBLY AND REASSEMBLY
(6) RemovethetwoM4L6bindingheadscrewsattachingthepenblock.
Pen block
M4L6 binding
head screw
How to reinstall the pen block
(1) AttachthepenblocktotheY-slider.
(2) MovethepenblocktocenteroftheYbarandlowerthepinchrollerwhenmeasuringthepenblock
height.
(3) FastenthetwoM4L6bindingheadscrewstoattachthepenblocksothatthereis
agapof10mm
(CE5000-120AP:11.5mm)betweenthebottomofthepenblockandthecuttingmat.Performa
visualchecktomakesurethatthepenblockisnotmountedatanangle.
10 mm
Cutting mat
Side view of the pen block
CE5000-40/60/120:
11.5 mm
CE5000-120AP:
(4) Reattachtheotherpartsinthereverseorderinwhichtheyweredetached.
(5) Performthepenforceadjustment(seeSection7.5).
(6) PerformtheautoregistrationmarksensoroffsetadjustmentfortheCE5000-40/60/120(seeSection7.9).
