6 DISASSEMBLY AND REASSEMBLY
6.2.10 How to Replace the Y-belt
How to detach the Y-belt
(1) Detach the right and left side covers (see Subsection 6.1.1 and Subsection 6.1.2).
(2) Detach the center cover (see Subsection 6.1.3 or 6.1.4).
(3) Detachthepenblock(seeSubsection6.2.5).
(4) LoosentheM3L6TPheadscrewattachingtheY-tensionarm.
(5) PushtheY-tensionarminthedirectionofthearrowasshownbelow,thendetachtheY-tensionspring
hookfromtheleftsideplate.
M3L6 TP head screw
Y-tension bracket
Y-tension arm
Y-tension spring
(6) RemovethefourM3L6bindingheadscrewsattachingtherightandleftY-beltstopperplatestothe
slider.
Y-belt
Y-slider
Y-belt stopper plate
M3L6 binding head screw
(7) DetachtheY-beltfromtheunit.
