CE5000-UM-251-9370 6-41
6 DISASSEMBLY AND REASSEMBLY
6.2.19 How to adjust the height of the grid drive shaft
Preparation of adjusting
(1) Detach the front and rear guide.
(2) Detach the center cover.
Gridrollersupportbracket
FrontHeightadjustmentScrew
Make a hole here
RearHeightadjustmentScrew
Y-rail
Grid drive shaft
