12 / 24
S1032_mz-8P_V1.1sh
Removing the transmitter batteries
If the transmitter is not going to be used for a long time, the batter-
ies should be removed from the device to avoid damages to the
transmitter due to electrolyte leaks.
Data socket
The data socket is used to connect an optional Bluetooth module as
well as to update the transmitter or change its control mode.
Accessories
• SMART-BOX, No. 33700
Display and programmer for telemetry data and devices
• external Bluetooth module, No. S8351
for wireless transmission of telemetry data to a compatible
Android ™ smartphone and comfortable programming of receiv-
ers and sensors via smartphone.
• USB interface No. S8500
• micro USB cable, No. 33002.OTG
for wired display of telemetry data on one and programming via
Android ™ smartphone
Factory reset
If necessary, all values stored in the transmitter can be deleted by a
reset and reset to the factory settings. To do this, proceed as follows:
Push and hold all the trims to the inside and then switch the trans-
mitter on.
Note
All settings made in the meantime are reset to the default values!
Starting up the transmitter
To switch on the transmitter, push the POWER button to the front.
Immediately after switching on, a short beep will sound; the yellow
motor OFF LED lights up and the central status LED of the transmit-
ter lights up or flashes depending on the current status.
Status Description Red status LED Red LED Yellow LED Green LED Buzzer
Binding Tx unbound Blinks 1x / sec 1x low
Tx bound ON 2x low
Correct contact to rx ON 2x low
Range test Blinks quickly 2x low / 2sec
Error Tx volt too low Blinks quickly 4x high / 2sec
Sensor warning 3x high / 2sec
