15 / 24
S1032_mz-8P_V1.1sh
the "SPEED" and "SNAP" buttons, the range test can be stopped
earlier at any time.
10. Perform a range test before each flight, and simulate all control
movements that could occur during the flight. In order to guar-
antee a safe model operation, the range must always be at least
5 - 10 m on the ground.
Attention
Never start a range test on the transmitter during normal model
operation!
Stick calibration
If the middle position of your self-neutralizing stick does not exactly
correspond to 0% control course, then you can check it yourself and
correct it if necessary.
Stick calibration step by step
1. Eventually disconnect the copter by unplugging the battery.
2. Put the transmitter into programming mode by pressing and
holding the left control stick.
An acoustic signal sounds and the central red LED flashes 3 times
per second.
About another three seconds later, an acoustic signal sounds
again.
3. Now successively move both joysticks to the respective end stops
and then back to the middle.
4. Keep both sticks in the middle position.
After approx. 3 seconds, an acoustic signal sounds and the cen-
tral red and the yellow "Acro" LEDs on the top right flash 3x each
3x per second.
5. Now press the left stick for about one second.
As soon as the left, yellow, "motor OFF" LED lights up and the cen-
tral red LED flashes slowly, the process has been completed cor-
rectly and the stick can be released. Otherwise the entire process
has to be repeated.
6. The copter can be put back into operation.
