Firmware update
Firmware updates of the transmitter are carried out via the back
DATA connection with the aid of a PC with Windows 7 ... 10. You will
also need a USB interface, order no. 7168.6, and adapter lead, order
no. 7168.6A or 7168.S, which are available separately.
The programs and files required can be found in the Download area
for the corresponding products at www.graupner.de.
Connect the adapter lead to the USB interface. The polarity of the
plug-in system cannot be reversed. Note the small chamfers on the
sides. Do not use force, the plug should click into place easily.
Plug the other end of the adapter cable into the jack marked "S + -"
on the back of the transmitter upon the battery case. Do not apply
force. The plug should be pushed all the way in with the black or
brown cable facing the right side of the "-" pin.
The update is carried out via the "HoTT Device" or "HoTT device"
program section of the "Firmware_Upgrade_gr_Studio" program
found under "Device" or "Devices". Please follow the notes of the
software. The further procedure is also described in detail in the
manual contained in the data package. You can also download these
from the download page of the product at www.graupner.de.
