21
Description of transmitter: screen contrast, position display, servo display
… and for model helicopters:
Bar 1 = Collective pitch or roll (2) or pitch-axis (2) servo
Bar 2 = Roll (1) servo
Bar 3 = Pitch-axis (1) servo
Bar 4 = Tail rotor servo (gyro)
Bar 5 = Pitch axis (2) servo / free channel
Bar 6 = Throttle servo / speed controller
Bar 7 = Gyro gain / free channel
Bar 8 = Speed governor / free channel
Note:
Please note, however, that the servo display always
refers to the original servo sequence, i. e. if you swap
over the receiver outputs using the sub-menu “receiv
out” in the »base sett.« menu (see pages 49 or 53), the
display does not refl ect this. The same applies if you
use the receiver interchange facility (see page 26, or the
instructions supplied with the receiver).
