48
Program description: basic settings – fi xed-wing model
Timers
Two timers are shown in the basic display: one stop-
watch and one fl ight timer.
GRAUBELE
#01
5:30h
stop
flt
«normal »
K78
IFS
0:00
0:00
9.6V
You can assign a physical switch or a control switch to
these tw
o timers in the “Timers” line …
normal
tail type
motor on C1
no
aile / flap
2aile
clock 0:00
SEL
SEL
… using the switch symbol on the right-hand side. The
assigned switch starts both timers, and also halts the
stopwatch.
The method of assigning a physical switch or a control
switch is described on page 33.
The fl ight timer always starts simultaneously with the
stopwatch, but continues to run even when the stop-
watch is halted (switched off). It can only be stopped by
pressing ESC with the stopwatch halted.
Once stopped, pressing CLEAR resets both timers to
the initial v
alue.
Switching between “count-up” and “count-down”
Count-up timer (stopwatch function)
If you assign a switch and start the stopwatch with the
initial value of “0:00”, the timer runs up until the maxi-
mum of 999 minutes and 59 seconds, then re-starts at
0:00.
Count-down timer (alarm timer function)
You can use the left-hand SEL fi eld to select a start-
ing time within the range 0 to 180 minutes; using the
right-hand SEL fi eld the range is 0 to 59 seconds. Any
combination of times can also be selected.
(CLEAR = “0” or “00”.)
10:01
SEL
SEL
C2
normal
tail type
motor on C1
no
aile / flap
2aile
clock
Procedure
Select the 1.
SEL fi eld with the rotary cylinder.
Press the rotary cylinder.2.
Select the required time in the highlighted minutes 3.
and seconds fi elds using the rotary cylinder.
Press the rotary cylinder to conclude the input pro-4.
cess.
Once you have switched back to the basic display, press
the CLEAR button fi rst with the stopwatch halted, so
that the stopw
atch switches to the “Timer” function; see
top right in the next illustration.
GRAUBELE
#01
5:32h
stop
flt
«normal »
K78
IFS
10:01
0:00
9.6V
When you operate the assigned switch, the stopwatch
star
ts from the set initial value, counting down (“Timer
function”). When the set time has elapsed, the timer
does not stop, but continues to run so that you can read
off the time elapsed after reaching zero. To make this
clear, the over-run time is shown highlighted (inverse
video).
Sequence of sounds
30 sec. before zero: triple beep
single beep every two seconds
20 sec. before zero: double beep
single beep every two seconds
10 sec. before zero: single beep
single beep every second
5 sec. before zero: single beep every second at higher
rate
zero: longer beep; display switches to
inverse video
The “alarm timer” is reset by pressing the CLEAR button
once y
ou have halted the timer.
Note:
A count-down timer is indicated in the basic display by
a fl ashing colon (:) between the minutes fi eld and the
seconds fi eld.
