54
Program description: basic settings – model helicopter
are not swapped over.
With the rotary cylinder held pressed in, select the servo
/ output combination you wish to change, then press
ENTER or the rotary cylinder. Now you can assign the
desired ser
vo(s) to the selected output using the rotary
cylinder … or alternatively press CLEAR to revert to the
default sequence.
Please note that any subsequent changes to servo
settings, such as servo travel, Dual Rate / Expo, mixers
etc., must be carried out according to the original
(default) receiver socket sequence.
Note:
It is also possible to swap over the outputs of XR-series
receivers at the receiver itself, as described on page 26
and in the instructions supplied with the actual receiver.
However, we strongly recommend that you use only one
of the two options, as a combination will soon lead to
confusion.
Typical applications:
In the helicopter program of the •
mx-16iFS the out-
puts for one collective pitch servo and the throttle
servo have been interchanged compared to all earli-
er GRAUPNER/JR mc-systems. The throttle servo is
now assigned to receiver output “6” and the collective
pitch servo to output “1”. You may therefore wish to
retain the earlier confi guration.
It may also prove necessary to swap servos for Trai-•
ner mode operations, if you are using a model set up
for another make of equipment fi tted with a Graup-
ner | iFS RF module, to avoid having to re-connect
the servos at the receiver.
S
S
S
S
6
2
3
4
1
2
3
4
output
SEL
S
S
S
S
5
7
8
5
6
7
8
1
output
output
output
output
output
output
output
