- RF ON/OFF
It is used to turn on or off transmitter’s “RF” function. If you are not ying a model but
programming transmitter only, you are able to save the battery of the transmitter by setting
RF to turn off. Under “OFF” status, transmitter is disconnected with the receiver. Touch “ON”
icon in “RF ON/OFF” to change to “OFF”
- RF TYPE
mz-24 offers 3 RF types, NORMAL, FRANCE and AMERICA to comply with country regu-
lation. “NORMAL” type is usually used in most countries, but you need France RF setting
to comply with France regulations in FANCE. France RF setting should only be turned on
when operating your transmitter in France outdoors. “NORMAL” type can be changed into
“FRANCE” type by touching “NORMAL” icon. If the “FRANCE” icon is touched again, it can
be changed into “AMERICA” icon.
Touch
Touch Touch
Touch
- RANGE TEST
“Range Test” function reduces the power output. This allows for a range test to conrm the RF link
is operating correctly. Perform a range check at the beginning of each ying session to conrm
system operation.
If the servo connected to receiver is operated normally within 30m or 50m of the distance from the
receiver, you may y a model, if not, you need do range test again. If it doesn’t operate normally
even after the test, please send mz-24 for repair.
Touch “OFF” icon in “RANGE TEST” to change to “ON”, transmitter beeps indicating “Range test”
setup begins. This function is available for 99sec. you may touch “ON” icon if you want to stop the
function.
Touch Touch
19
