10. TRIM STEP

It allows you to check all values of “Digital trim step”, “DT1”, “DT2”, ‘Digital volume”, and “Side

slide”. Touch “Trim Step” icon in base menu page to call Trim Step setup page. The step values in

T1, T2, T3, T4 indicate servo movement per click of trim. “4” is set by default, which means that

trim will travel as much as 4 by each click of trim

Touch and activate the step values and then adjust them with INC” and “DEC” buttons. Now you

may adjust trim amount with the step value in actual ight and you may check the adjusted trim

amount in “POS” line. If trim amount reaches to the range limit of -30% ~+30%, you may not adjust

trim amount again. So you need to save the programmed trim amount on the transmitter. If trim

amount is saved, it is reset to 000% automatically. To save and reset, touch and activate the val-

ues, 000%, in SET line and touch “SET” icon in the right bottom, then the programmed trim amount

in “POS” line is transfer to “SET” line and the value in POS line is reset to 000%.

Now, you may adjust the value of “Digital trim 1” and ‘Digital trim 2”. Their default value is set as

“None”. Touch any of options for ‘DT1” and “DT2” to activate in blue. You may adjust the function

value with “INC” and “DEC” buttons. Touch “View” icon in the right to call the next page that you

can see all setup data such as Trim position, DT1, DT2, Digital volume and Side slide. Touch

“BACK” icon to return the previous page.

TouchTouch

Touch
