EN - 16
See Figure 9 for all controls and features
locations.
IGNITION KEY
See Figure 10.
Controls power to the engine. The key cannot
be removed when in on position.
CHOKE CONTROL LEVER
Models 992267, 992268, 992269, 992270
See Figure 11.
Controls air intake to the engine.
THROTTLE CONTROL LEVER
See Figure 12.
Controls engine speed.
POWER TAKE-OFF (PTO)
SWITCH
See Figure 13.
Controls power to mower blades. The engine
will not start with the PTO switch in the on
position.
FUEL VALVE
Controls fuel flow to the engine. Directs fuel
from left or right fuel tank or stops all fuel flow.
WARNING: AVOID INJURY.
Read and understand the Safety
section before proceeding.
Figure 11
Choke On
Choke Off
Figure 13
PTO / Blades On
PTO / Blades Off
