Jaguar II User Manual
3.3 Description of Menu Items
This describes the items and functions available when you press
Menu or Key Function Setting Default
Roll: Sizing media width. Tracking
25 meters
Edge Sizing media width and pull the media back until
the front paper sensor open
Tracking
25 meters
Media sizing
Single Sizing media width and length Tracking
10 meters
Speed This sets the speed when the blade is down and
moves for cutting.
3-153cm/s
Step (3cm/s)
72cm/s
Up Speed This sets the speed when the blade is raised
and moves to the next position for cutting during
a cutting operation
3-153cm/s
Step (3cm/s)
72cm/s
[Speed Key]
Cutting Quality This sets the cutting quality.
When cutting small letter, set it to Small letter.
When cutting at very fast speed, please set it to
“Draft”. For normal operation please set it to
“Normal”.
Draft
Fair
Normal
Fine
Small Letter
Normal
[Force Key]
This set the force for the blade during cutting. 600gram
5 gram/step
80 gram
[Offset Key]
This set the offset value for the blade during
cutting.
0.000-1.000mm 0.275mm
[Arrow Key]
1. Move the carriage position on x-axis and
y-axis
2. Choose the functions and change the value
of the setting.
[Enter]
1. Press it to effect the displayed parameters.
The displayed parameters will be saved
automatically.
2. To set a new origin at the present tool
carriage position.
[Enter] Set New Origin
In “offline” mode,
Press [ARROW KEY] to move the tool carriage
to the desired location. Then, press [ENTER
KEY] to set new origin.
While moving, the x-axis and y-axis are
displayed.
Description of Operation 3-3
