Jaguar II User Manual
6.3 Cutting Plotter/Computer Communication Problems
The messages showed below present problems in relation to cutting plotter/computer
communication.
Communication Error
Setup: MISC. key
Yes No
Has the interface setting been
done correctly?
Refer to Chapter 4 -
Connecting your cutting
lotter.
Yes
Try the communication
between your cutting plotter
and computer. If it still does
not work, have your cutting
lotter serviced.
N o
Refer to the āMISCā key in
Chapter 3 - Description of
Operation for the port setup.
Is the connection cable connected
to the cutting plotter and computer
roperly?
Note:
The computer also needs to set up compatible communication parameters to the
cutting plotter set up.
If your cutting plotter can not recognize the
HP-GL/2 or HP-GL commands, please chec
the HP-GL/2 or HP-GL commands applied to
your cutting plotter are used properly.
HP-GL/2 Cmd. Error
Troubleshooting 6-3
