Jaguar II User Manual
Jaguar II Specifications
Model : Jaguar JII-61 JII-76S JII-101S JII-132S
Operational Method Roller-Type
Max. Cutting Width 610mm (24.0in) 760mm (29.9in) 1016mm (40in) 1320mm (52in)
Max. Media Loading Width 770mm (30.3in) 920mm (36.2in) 1270mm(50in) 1594mm(62.8in)
Number of Pinch Rollers 3 4
Min. Media Loading Width 50mm
Acceptable Material Thickness 0.8mm (0.04in)
Drive DC Servo Control
Cutting Force 0~600 g
Max. Cutting Speed 1530 mm/sec (60ips, Diagonal)
Tangential- emulation Yes
Paper Cutting Ability Yes
Sliter Groove & Tool Yes
Media Basket Optional
Acceleration 4.2 G (gravity)
Offset 0~1.0 mm (with an increase of 0.025mm)
Mechanical Resolution 0.00625mm
Software Resolution 0.025 mm
Repeatability 0.1mm
Buffer Size 4 MB
Interfaces USB, Parallel and Serial (RS-232C)
Commands HP-GL, HP-GL/2
Configurable Origin Yes
Curve & Arc Smoothing Yes
Test Cut capability Yes
Replot Function Yes
Copy Function Yes
Pouncing Function Yes
Control Panel LCM (20 digits x 2 lines), 14 Keys, 1 Power LED
Dimension (HxWxD) mm
(HxWxD) in
414 x 930 x 490
16.3 x 36.6 x19.2
1166 x 1080 x 667
45.9 x 42.5 x 26.3
1166 x 1430 x 667
45.9 x 56.0 x 26.3
1166 x 1754 x 667
45.9 x 69.1 x 26.3
Net Weight (kg) 37.2kg 40.5kg 53.3kg 61.0kg
Power Supply AC 100~240V (auto switch)
Power Consumption Max. 110watts
Environment Humidity 30% ~ 70% relative humidity (operating)
Environment Temperature
0°C~55°C / 32°F~131°F(operating)
-40°C~75°C / -40°F~167°F(storage)
The above specification is subject to change without prior notice.
Stand for Jaguar JII-61 is optional.
