DC INVERTER MULTI VRF PRODUCT
11
kW 14.0 16.0
Cooling①
Btu/h 47768 54592
kW 15.4 17.6
Capacity
Heating②
Btu/h 52545 60051
Sound Pressure Level dB(A) 58 60
R410A Filling Amount kg 7.5 7.5
Power Supply V,Ph,Hz 220V-240V~,1Ph,50Hz 220V-240V~,1Ph,50Hz
Cooling kW 4.36 4.98
Power input
Heating kW 4.05 4.85
Cooling A 20.5 23.2
Rated current
Heating A 19.6 21.9
Compressor DC inverter dual-rotor type compressor×1
Moisture protection
IP×4 IP×4
Climate Type T1 T1
mm
φ15.9 φ19.05
Gas Pipe
Inch
5/8＂ 3/4＂
mm
φ9.52 φ9.52
Liquid Pipe
Inch
3/8＂ 3/8＂
Connection Method Flare Connection Flare Connection
Connection Pipes
Max. NO. of Indoor Unit 7 8
Power input kW 0.136 0.184
m
3
/h 6000 6800
Air Flow Rate
CFM 3538 4010
Fan
Step 3 3
Recommended Power Lines mm
2
×Number
10.0×3 10.0×3
Circuit breaker A 40 40
Dimensions of Installation mm
1650×590×1700 1650×590×1700
Width mm 950 950
Depth mm 340 340
Unit Dimensions
Height mm 1250 1250
Width mm 1110 1110
Depth mm 450 450
Dimensions of
Package
Height mm 1280 1280
Weight(Net/Gross) kg 135/140 135/140
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling
only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
