DC INVERTER MULTI VRF PRODUCT
12
4.2 Product data of indoor
4.2.1 Duct Type
Model GMV(L)-R22P/Na-K GMV(L)-R25P/Na-K GMV(L)-R28P/Na-K
kW 2.2 2.5 2.8
Cooling Capacity
Btu 7506 8530 9554
kW 2.5 3.0 3.2
Heating Capacity
Btu 8530 10236 10918
m3/h 450 450 570
Air Flow Rate
CFM 265 265 336
Sound Pressure Level (H/L) dB(A) 37/33 37/33 39/35
External Static Pressure Pa 25 25 25
Power Supply
220-240V～50Hz 220-240V～50Hz 220-240V～50Hz
Output kW 0.02 0.02 0.02
Fan Motor
Running Current A 0.17 0.17 0.16
mm
φ9.52 φ9.52 φ9.52
Gas Pipe
inch
3/8＂ 3/8＂ 3/8＂
mm
φ6.35 φ6.35 φ6.35
Liquid Pipe
inch
1/4＂ 1/4＂ 1/4＂
Connecting
Pipes
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm
φ20×1.5 φ20×1.5 φ20×1.5
Unit Dimensions
(W×D×H)
mm 875×680×220 875×680×220 875×680×220
Package Dimensions
(W×D×H)
mm 1012×708×275 1012×708×275 1012×708×275
Weight（Net/Gross）
kg 27/31 27/31 27/31
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling
only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
To Next Page
