DC INVERTER MULTI VRF PRODUCT
13
Model GMV(L)-R32P/Na-K GMV(L)-R36P/Na-K GMV(L)-R40P/Na-K
kW 3.2 3.6 4.0
Cooling Capacity
Btu 10919 12284 13649
kW 3.6 4.0 4.5
Heating Capacity
Btu 12283 13648 15354
m3/h 570 570 840
Air Flow Rate
CFM 336 336 494
Sound Pressure Level (H/L) dB(A) 39/35 39/35 40/36
External Static Pressure Pa 25 25 20
Power Supply
220-240V～50Hz 220-240V～50Hz 220-240V～50Hz
Output kW 0.02 0.02 0.07
Fan Motor
Running
Current
A 0.16 0.16 0.69
mm
φ12.7 φ12.7 φ12.7
Gas Pipe
inch
1/2＂ 1/2＂ 1/2＂
mm
φ6.35 φ6.35 φ6.35
Liquid Pipe
inch
1/4＂ 1/4＂ 1/4＂
Connecting
Pipes
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm
φ20×1.5 φ20×1.5 φ30×1.5
Unit Dimensions
(W×D×H)
mm 875×680×220 875×680×220 980×736×266
Package Dimensions
(W×D×H)
mm 1012×708×275 1012×708×275 1068×766×320
Weight（Net/Gross）
kg 27/31 27/31 36/39
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling
only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
