Gree DC Inverter Multi VRF

DC INVERTER MULTI VRF MAINTENANCE
233
No. Part Name Code Qty.
1 Front Plate 01435436 1
2
Rear Grill
01475432 1
3 Top Cover 01255262 1
01124159①
4 Condenser Assy
01124158②
1
5
Electric Box Cover
01424235 1
6
Clapboard
01244132 1
7
Retaining Plate
01844135 1
01394528③
01394799④
01394802⑤
8 Electric Box Assy
01394797⑥
1
9
Main Board
30226217 1
10
Filter Board
30228115 1
11
capacitance
33010037 2
12
Bipolar Air Switch
46020018 1
13
Terminal Board
42011242 1
14
Connection Pipe
05024915 1
No. Part Name Code Qty.
15 Inhalation Tube Sub-Assy 04674170 1
16 LOW PRESSURE SWITCH 46020007 1
17 Capillary Sub-Assy 04104154 1
18 Capacitor 4312002101 1
19 Gas by-pass valve sub-assy 07334329 1
20 Electromagnetic Valve 43000054 1
21 Rear Side Plate Sub-Assy 01314212 1
22 Solenoid Coil 4304000403
1
23 Handle 26235253 2
24 Connection Pipe 05024911 1
25 Front Side Plate Sub-Assy 01305430 1
26 Connection Pipe 05024916 1
27 Discharge Tube Sub-Assy 04634226 1
28 Pressure Protect Switch 4602000902 1
29 Discharge Tube Sub-Assy 04634227 1
30 High-pressure Accumulator 07228739 1
31 Valve Support Sub-Assy 01715001 1
32 Cut-off Valve 07130209 1
07103030⑦
33 Cut-off Valve
07130212⑧
1
34 EXV sub-assy 07334161 1
35
Electric expand vavle
07334102 1
36 Retaining Plate Sub-Assy 01844134 1
37
Compressor
01844134P 1
38
Clapboard
00205224 1
39 Motor Support 01244112 1
40
Base Plate Sub-Assy
01804113 1
41
Axial Flow Fan φ472X165
01194133P 1
42 Fan Motor
15013302⑨
2
