GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
285
No.
Name of part
GMV-280WM/E1-X
Product Code
CN851W2200
Part code
Quantity
29
Bidirectional Filter
07210044
1
30
Electronic Expansion Valve Sub-Assy
07334100030
1
31
Left Side Plate
01314712P
1
32
Chassis Sub-assy
01194708
1
33
Gas-liquid Separator
07424188
1
34
Base Frame Assy
01284711
1
35
Oil Separator
0742418601
1
36
Electrical Heater(Compressor)
7651873209
1
37
Compressor and Fittings
00204100002
1
38
Electric Heater(Compressor)
7651540713
1
39
Magnet Coil
4304000423
1
40
Magnet Coil
4304000415
1
41
Gas Tube Filter
072190511
1
42
Cut-off Valve
07334100011
1
43
Oil Equalizing Pipe Sub-Assy
04224100148
1
44
Oil Separator
07424100023
1
45
Pressure Switch
4602000911
1
46
Discharge Tube Sub-assy
04534100050
1
47
Front Panel
01544627P
1
48
Handle
26904100016
2
49
Front Panel
01544620P
1
50
Temperature Sensor Sub-Assy
39008000006G
1
51
Pressure Sensor
32218000009
1
52
Pressure Sensor
32218000008
1
53
Right Side Plate
01314713P
1
54
4-Way Valve Sub-Assy
04044100013
1
55
Cut-off Valve 1-1/8
07334100014
1
56
Filter
07218603
1
57
Magnet Coil
4300040032
1
58
4-way Valve
43000339
1
59
One way Valve
07335210
1
60
Nozzle for Adding Freon
06120012
2
61
Filter Board
30228000015
1
62
Rectifier
46010604
1
63
Reactor
43138000034
1
64
Main Board
30228000010
1
65
Electric Box Assy
01394100191
1
66
Radiator
49018000002
1
67
Main Board
30229010
1
68
Radiator
49018000001
1
69
Terminal Board
42010247
1
70
Main Board
30223000005
1
71
Terminal Board
42018000026
1
Above data is subject to change without notice, pls reference the SP in global service website.
