GREE
GMV5E DC
INVERTER
VRF
UNITS SER
VICE
MANUAL
290
No.
Name of part
GMV
-400WM/E-X
GMV
-450WM/E1-X
Product Code
CN851W1820
Product Code
CN851W2210
Part code
Quantity
Part code
Quantity
42
Magnet Coil
4304000423
1
4304000423
1
43
Magnet Coil
4304000414
1
4304000414
1
44
Oil Equalizing Pipe
Sub-Assy 2
04224100059
1
04224100059
1
45
Compressor and Fittings
002041
16
1
002041
16
1
46
Electric
Heater(Compressor)
7651540714
1
7651540714
1
47
Compressor
00204100002
1
00204100002
1
48
Electric
Heater(Compressor)
7651540713
1
7651540713
1
49
Front Panel (Left)
01544100003P
1
01544100003P
1
50
Front Panel (Right)
01544100005P
1
01544100005P
1
51
Handle
26904100016
2
26904100016
2
52
Cover Plate
01264100004P
2
01264100004P
2
53
Sensor Sub-Assy
39008000028G
1
39008000028G
1
54
Pressure Sensor
32218000009
1
32218000009
1
55
Pressure Sensor
32218000008
1
32218000008
1
56
Suction Pipe Sub-Assy
04574100039
1
04574100039
1
57
Oil Separator
07424100023
2
07424100023
2
58
Pressure Switch
460200091
1
1
460200091
1
1
59
Pressure Switch
4602000912
1
4602000912
1
60
Exhaust T
runk Sub-Assy
04534100012
1
04534100012
1
61
Check V
alve
07333700032
2
07333700032
2
62
Gas By-pass Sub-
Assy
04514100036
1
04514100036
1
63
Magnet Coil
4304000402
1
4304000402
1
64
4-W
ay V
alve Sub-Assy
04044100019
1
04044100019
1
65
Filter
07218603
1
07218603
1
66
Magnet Coil
4300040030
1
4300040030
1
67
4-way V
alve
43000339
1
43000339
1
68
Check V
alve
07335210
1
07335210
1
69
Nozzle for
Adding Freon
06120012
2
06120012
2
70
Right Side Plate
01314713P
1
01314713P
1
71
Electric Box
Assy
01394100104
1
01394100104
1
72
Reactor
4313017401
1
4313017401
1
73
Filter Board
30228122
1
30228122
1
74
Rectifier
46010058
1
46010058
1
75
Main Board
30228609
1
30228609
1
76
Rad
iator
49018000001
1
49018000001
1
77
Electric Box
Assy
01394100085
1
01394100085
1
78
Filter Board
30228000015
1
30228000015
1
79
Rectifier
46010604
1
46010604
1
80
Main Board
30228000010
1
30228000010
1
81
Reactor
43138004
1
43138004
1
82
Main Board
30229009
2
30229009
2
83
Radiator
49018000001
2
49018000001
2
84
T
erminal Board
42010247
1
42010247
1
85
Main Board
30223000005
1
30223000005
1
86
T
erminal Board
42018000026
1
42018000026
1
Above data is subject to chan
ge without notice, pls reference the SP in global service website.
293
295
