910FS Splicer
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
42
Error Message Reason Solution
Display “Wait
Download..”
ON/OFF and ENTER buttons are held
at the same time.
Power off. Power back on.
Component damage – keypad. Keypad replacement required.
LEFT_FIBER_DIRTY
RIGHT_FIBER_DIRTY
LR_FIBER_DIRTY
Fibers are dirty. Clean ber and recleave.
V-grooves are dirty. Clean V-grooves.
V-grooves are damaged. V-grooves need to be factory replaced.
Fiber presser foot is dirty. Clean presser foot of 910CL.
Fiber adapters are dirty. Clean ber adapters.
Mirrors are dirty. Clean mirrors .
Lenses are dirty. Clean lenses.
LR_ARC_VALUE_ERR Fibers are dirty, passing the limit of
checking process.
Clean ber and recleave.
Cleave angle is too big. Recleave bers to obtain good cleave
angle.
Failure to do the arc calibration. Do arc calibration.
Electrodes are oxidized. Clean electrodes or replace with a new pair.
Lenses are dirty. Clean lenses.
FIBER_PUSH_ERR Fiber is not in V-groove. Replace ber and check if ber is in the
V-groove.
Fiber holder is not tight. Reposition the ber.
Backward tension is on ber. Release any tension on ber.
The adapter holder is dirty. Clean the ber adapter holder.
ARC_OFFSET_TOO_
LARGE
Failure to do the arc calibration. Do arc calibration.
Electrodes position error. Check and or replace electrodes.
Electrodes are broken. Replace electrodes.
Electrodes are oxidized. Replace electrodes.
LENS_OFFSET_TOO_
LARGE
Fiber is beyond observation range. Perform “Screen Adjust” to allow bers to
be displayed on the screen.
COVER_OPEN when the
windshell is closed
The magnet on windshell is missing. Magnet needs to be factory replaced.
Notied to replace
electrodes
Electrodes require calibration or
replacement.
Stabilize electrodes as per Menu 3; replace
electrodes.
Error Messages (cont’d)
