21
4.3 Programs
4.3.1 Create a program.
1. Select the desired or free program number (press and hold down for two seconds)
2. Name program (enter name)
3. Define processes as described in Section 4.2
4. Total process time is displayed at the top right.
4.3.2 Standard programs (pre-installed)
Four programs are pre-installed on the device ex works. These can be applied as they are, adapted or overwrit-
ten.
The setting parameters of the predefined programs are as follows:
Program name: GVL STANDARD
Total process time: 36:30 min
Pos. 1 Pos. 2 Pos. 3 Pos. 4 Pos. 5 Pos.6
05:00 04:00 02:00 01:30 01:30 10:00
20
300 300 300 300 50
Vertical movement (on/off)
Off On Off Off Off Off
- Red Red Red Red -
– 5) - - - - - -
