Greiner Vibrograf ACS921 - Baths and Containers; Position and Baths; Container

36
4.4 Baths and containers
4.4.1 Position and baths
Position Description
Position 1 Cleaning bath (with or without ultrasound)
Ultrasound selectable at 40 kHz or 80 kHz or combined 40/80 kHz
Position 2 Cleaning bath
Position 3 Cleaning bath or rinsing bath
Position 4 Cleaning bath or rinsing bath
Position 5 Cleaning bath or rinsing bath
Position 6 Drying at max. 60 °C/cooling position/loading position for baskets
4.4.2 Containers
Ultrasound container Glass container
Fill glasses up to the mark with the appropriate cleaning or rinsing solution (max. 0.55 l).
The ultrasound tray also has a marking; the maximum capacity is 0.55 l.
Never use the ultrasonic container without or with too little cleaning liquid.
Otherwise, overheating with consequential damage may occur.
