44
SECUREconnect 100
6.2 LED signalling
The LED indication of SECUREconnect 100 is an important means during start-up or when it
comes to trouble shooting. It provides information on the different statuses of the device.
6.2.1 LED indication on SECUREconnect 100R
LED green / LED red
0.5 Hz ashing alternately
Normal status, uncoded,
no communication with other devices linked to the GU-BKS-NET bus
LED green / LED red
1 Hz ashing alternately
Normal status, uncoded,
communication with at least one device linked to the GU-BKS-NET bus
LED green
0.5 Hz ashing
Normal status, coded,
no communication with other devices linked to the GU-BKS-NET bus
LED green
1 Hz ashing
Normal status, coded,
communication with at least one device linked to the GU-BKS-NET bus
LED red
2 Hz ashing
Temperature too high
LED red
5 Hz ashing
Trouble:
Short circuit
Display with door open and closed.
6.2.2 LED indication on SECUREconnect 100F
LED green
1 Hz ashing
Normal status, uncoded,
LED green
0.5 Hz ashing
Normal status, coded,
LED green
off
Power supply between SECUREconnect 100R and 100F interrupted
for a longer period of time
LED green
5 Hz ashing
Trouble:
Short circuit, switch-off, capacitors....
Display with door closed, and up to 15 s after door opening
Explanation:
5 Hz = 5 ashes per second
2 Hz = 2 ashes per second
1 Hz = LED 0.5 seconds on, 1 ash per second
0.5 Hz = LED 1 second on
