Power and Data Transmission Unit
6.5 Electrical function test
In order to verify if an assembly group has been connected properly, it is necessary to carry out
the following work steps:
1. Close door manually
2. Apply supply voltage to SECUREconnect 100R (e.g. 230V AC by means of a Europlug)
3. Bridge brown and white wire of connecting cable on SECUREconnect 100R
The lock function 'short-time OPEN' will be activated causing the electrical lock to unlock and
the outside lever handle to engage for a short moment, each.
