GRISWOLD PUMP COMPANY Spart Parts Page 37
Installation, Operation and Maintenance Manual
Griswold Model 811
Griswold Pump Company Spare Parts Page 39
Spare Parts
We recommend that, as a minimum, the following parts be kept on hand as spares:
Part Description (Item Number) – refer to pump cross-sectional view in Appendix VIII, page 49.
Recommended Spares – All Pumps
Impeller (101) Bearing Lockwasher (382)
Shaft (122A) Bearing Locknut (136)
Shaft Sleeve (126), if used Impeller O-ring (412A)
Outboard, Thrust Bearing (112A) Bearing Housing O-ring (496)
Inboard, Radial Bearing (168A) Outboard Lab Seal Rotary O-ring (497)
Casing Gasket (351) Outboard Lab Seal Stationary O-ring (497G)
Frame-to-Adapter Gasket (360D) Inboard Lab Seal Rotary O-ring (497H)
Bearing Housing Retaining Ring (361A) Inboard Lab Seal Stationary O-ring (497J)
Recommended Spares – By Pump Application
If Packed Stuffing Box Is Used: If Mechanical Seal Is used:
Lantern Ring Half (105), Qty 2 Spare mechanical seal, per application
Packing Set (106), 5 rings
Packing Gland (107)
Whenever a pump is dis-assembled, parts that have been under compression such as gaskets and
o-rings should be replaced during re-assembly. In this regard, maintenance kits are available
which contain a complete set of gaskets and o-rings for a given pump repair. This packaging
may be helpful in maintaining required parts in stores.
Ordering Parts
Parts are available through your local authorized Griswold distributor. Please provide serial
number for accurate identification.
