G0516 Lathe/Mill
Design Type ....................................................................................................Bench Model
Overall Dimensions:
Overall Length ..........................................................................................................44"
Overall Width ............................................................................................................23"
Overall Height ..........................................................................................................34"
Bed Width .............................................................................................................. 5
3
8"
Spindle Bore ..............................................................................................................
3
4"
Lathe and Drill Press Tapers..........................................................................Morse #3
Tailstock Taper ..............................................................................................Morse #2
Weight (Net) ......................................................................................................397 lbs.
Crate Size ..................................................................................51" L x 26" W x 32" H
Footprint ......................................................................................................16
1
2" x 43"
Lathe Capacity:
Swing Over Bed ......................................................................................................9
3
4"
Swing Over Saddle ....................................................................................................6"
Distance Between Centers ......................................................................................21''
Compound Travel ....................................................................................................2
1
4''
Cross Slide Travel ..................................................................................................4
1
4"
Tailstock Barrel Travel ..........................................................................................
1
2"
Spindle Speeds ..................................................150, 240, 490, 750, 1200, 2400 RPM
Feed Rate Range ..............................................................................2 @ .005" - .010"
Thread Range Inch ..............................8-40 TPI in 12 Steps (Gear changes required)
Thread Range Metric..............................................................................12 @ .4-3 mm
Leadscrew ..................................................................................................
3
4" - 10 TPI
Cross Slide Screw......................................................................................
9
16" - 12 TPI
Milling Capacity: (Measured without Drill Chuck)
Swing ....................................................................................................................12
3
4''
Spindle to Work Table ............................................................................................9
1
2"
Head Stock Height Adjustment ................................................................................ 8"
Range of Speeds ......................................................................................................
0-2500
RPM
Drill Capacity ............................................................................................................
1
2"
Lathe Motor:
Type ............................................................................TEFC Capacitor Start Induction
Horsepower ................................................................................................................
3
4
Switch ................................................................Forward/Reverse w/Emergency Stop
Phase ......................................................................................................Single-Phase
Voltage ..................................................................................................................110V
Amps............................................................................................................................9
RPM ......................................................................................................................1710
Mill Motor:
Type................................................................................................................DC Motor
Horsepower ................................................................................................................
4
5
Switch..................................................................................................Emergency Stop
Phase ......................................................................................................Single-Phase
Voltage ..................................................................................................................110V
Amps............................................................................................................................6
Speed ........................................................................................Variable, 0-2500 RPM
Features:
5" 3-Jaw Chuck 5" 4-Jaw Chuck
Cross Slide Table 8
1
2" Face Plate
12 Change Gears Quick Change Tool Post
Drill Chuck with Arbor 2 Dead Centers
Quick Change Lathe Spindle 4-Way Turret Tool Post
