Grizzly G0516 User Manual

G0516 Lathe/Mill -59-
REF PART # DESCRIPTION
801 P0516801 GEAR Z:72
802 P0516802 GEAR Z:70
803 P0516803 GEAR Z:68
804 P0516804 GEAR Z:66
805 P0516805 GEAR Z:60
806 P0516806 GEAR Z:50
807 P0516807 GEAR Z:48
808 P0516808 GEAR Z:45
810 P0516810 PIVOT SHAFT SPACER
811 P0516811 KNURLED KNOB
812 P0516812 DRIVE COVER
813 P0516813 GEAR Z:25
815 P0516815 ADJUSTABLE SHAFT
816 PN09M HEX NUT M12-1.75
817 P0516817 OIL CUP 6MM
818 P0516818 GEAR Z:80
819 P0516819 GEAR Z:33
820 P0516820 OPEN-END LOCK WASHER
821 P6001 BEARING 6001
822 P0516822 GEAR Z:40
823 PR03M EXT RETAINING RING 12MM
824 P0516824 FRONT SHAFT SPACER
REF PART # DESCRIPTION
825 P0516825 FIXED-SHAFT BOLT
826 P0516826 REAR SHAFT SPACER
827 P0516827 SUPPORT PLATE
828 P0516828 GEAR Z:40
829 PW01M FLAT WASHER 8MM
830 PB03M HEX BOLT M8-1.25 X 16
831 P0516831 SLIDING BEARING
832 P0516832 ADJ SHAFT SPACER
833 P0516833 GEAR REST
834 P0516834 ADJ SHAFT NUT
835 PS31M PHLP HD SCR M6-1.0 X 35
836 PK37M KEY 4 X 4 X 16
843 P0516843 MACHINE ID LABEL
844 P0516844 GEAR/SPEED LABEL
845 P0516845 GEAR Z:75
846 P0516846 GEAR Z:100
847 PLABEL-26 UNPLUG WARNING
848 PLABEL-27 CONVERSION CHART
849 PN04M HEX NUT M4-.7
850 PS63M PHLIP HD SCR M6-1.0 X 4
851 P0516851 HINGE
