Grizzly G0516 User Manual

-64-
G0516 Lathe/Mill
REF PART # DESCRIPTION
1017 PSB01M CAP SCREW M6-1.0 X 16
1029 PN01M HEX NUT M6-1.0
1030 P05161030 HANDLE
1039 P05161039 FUSELAGE SEAT
1039-1 P051610391 SHAFT
1039-2 PK70M KEY 8 X 8 X 12
1040 PLW06M LOCK WASHER 10MM
1040-1 PW04M FLAT WASHER 10MM
1041 PSB72M CAP SCREW M10-1.5 X 30
1042 P05161042 GUIDE FINGER
1043 PSS46M SET SCREW M6-1.0 X 22
1044 P05161044 RULER
1045 P05161045 WEDGE
1046 P05161046 GEAR RACK
1047 PSB26M CAP SCREW M6-1 X 12
1048 P05161048 HIGH/LOW NOTICE
1049 P05161049 SPINDLE BOX
1050 P05161050 PINION
1051 PK30M KEY 4 X 4 X 25
1052 P05161052 BEVEL GEAR
1053 PR03M EXT RETAINING RING 12MM
1054 P05161054 BALL 5MM
1055 P05161055 SPRING 0.8 X 0.8 X 10MM
1056 PS03M PHLP HD SCR M6-1 X 8
1057 P05161057 HANDLE STOCK
1058 P05161058 OPERATING LEVER
1059 P05161059 LEVER CAP
1060 P05161060 CAP SCREW
1061 P05161061 GUIDE FINGER
1062 PSB06M CAP SCREW M6-1 X 25
1063 P05161063 SPINDLE BOX SEAT
1064 P05161064 WEDGE
REF PART # DESCRIPTION
1065 P05161065 LIMIT BLOCK
1066 P05161066 WEDGE
1067 P05161067 RULER
1068 P05161068 FUSELAGE
1069 P05161069 ELECTRIC BOX
1070 PLN09 LOCK NUT M12- 1.75
1071 P05161071 BIG WASHER
1072 P05161072 CONNECTING STRUT
1075 PSB02M CAP SCREW M6-1.0 X 20
1078 PK02M KEY 5 X 5 X 40
1079 P05161079 SPINDLE
1080 P05161080 TRANSMISSION GEAR
1081 P05161081 SUPPORT BLOCK
1082 PS06M PHLP HD SCR M5-.8 X 20
1083 PRP60M PIN 4 X 15
1084 P05161084 WORM
1085 P05161085 SLEEVE
1086 PRP61M ROLL PIN 3 X 12
1087 PRP61M ROLL PIN 3 X 12
1088 P05161088 ADJUSTABLE UNION
1089 P05161089 BRACKET
1090 PS22M PHLP HD SCR M5-.8 X 25
1091 P05161091 DIAL
1092 P05161092 SPRING STEEL 1MM
1093 P05161093 SMALL HAND WHEEL
1094 PS40M PHLP HD SCR M5-.8 X 16
1095 P05161095 SMALL SHAFT
1096 P05161096 COVER
1097 PS17M PHLP HD SCR M4-.7 X 6
1098 P05161098 DUST COVER SUPPORT
1099 PS40M PHLP HD SCR M5-.8 X 16
