G0603X 25" Extreme Series Planer
-45-
Digital Control
Calibration
Tools Needed: Qty
Calipers ............................................................. 1
The value shown in the actual (bottom) LED
window of the digital control should be precisely
equal to the actual distance from the table to BDC
of the cutter carbide insert.
To calibrate the digital control:
1. Make sure that the all other adjustments are
correct as directed in this section, starting
with Table Parallelism on Page 36.
2. Plane a wide piece of stock making sure that
both top and bottom of the workpiece are as
parallel as possible.
3. Using the calipers, measure the thickness in
multiple places of the workpiece and record
the average value of these measurements.
4. Press the following keys on the digital con-
trol:
a. The "F" key
.
b. The "2" key
.
c. The ENTER key
.
Note: If this procedure is successful, an
LED in the top target window will blink, and
"OriGin" will appear in the top target window.
5. Enter the value that you recorded from Step
3 above, then press the ENTER key
.
Note: This step stores the actual value into
permanent memeory. Next, you will need
to complete the following steps to load that
value for operational use.
6. To load the actual value that was stored in
the previous steps, press the following keys:
a. The "F" key
.
b. The "0" key
.
c. The ENTER key
.
Note: If this step was successful, an LED will
blink in both windows, "CHAnGE" will appear
in the top window, and "OrG??" will appear in
the bottom window.
7. Press the ENTER key
to load and use
the stored value for the actual distance from
the table to the cutter insert.
